Why a Sample Earns Its Keep

There is a particular kind of optimism that seizes a weaver when a new idea arrives. You can see the finished throw, the cushion covers, the jacket panels — and you wind a ten-metre warp before you have checked whether the yarn you have chosen actually behaves in twill. A better habit is to spend an afternoon on a short sample warp first. Four shafts give you an enormous amount of ground to cover, and a sample of roughly 120 cm long by 20 cm wide is enough to test treadling sequences, colour combinations and finishing methods without risking a large piece of cloth.

Twill is a good place to start that conversation, because the structure is generous. Long floats give it drape and sheen, the diagonal lifts it out of plain weave, and small changes to the tie-up produce very different cloths from the same threading. All of that is worth exploring on a warp you can afford to cut up.

Choosing Yarns and a Sett You Can Trust

For a first four-shaft twill sample, choose a smooth, consistent yarn. A 2/8 cotton at around 18 ends per inch (epi) in the reed makes a crisp, well-behaved cloth that shows the diagonal clearly and washes predictably. A 4-ply wool at 10 to 12 epi gives a softer, fuller sample and is lovely for sampling finishing techniques, though the yarns need a little more care to keep the selvedges tidy.

As a rule of thumb, twill sits slightly closer in the reed than plain weave in the same yarn — often around 10 to 15 per cent closer. Long floats cover more ground per pick, but you still want the cloth firm enough that the diagonal does not snag or shift. If your first sample looks sleazy or the weft packs in unevenly, your next sample should be sett more closely. If the cloth feels boardy and the pattern is lost, go the other way.

• Keep the warp a single, consistent yarn while you are learning the structure.
• Save textured, slubby or novelty yarns for the weft, where an odd pick does less harm.
• Wind a warp long enough for at least four separate finished samples.

Building the Draft: Threading, Tie-Up and Treadling

The classic starting point is a straight draw: thread the heddles 1, 2, 3, 4, repeating across the width. Tie up four treadles so that each lifts two shafts — 1 and 2, then 2 and 3, then 3 and 4, then 4 and 1. Treadle them in that order and you have a balanced 2/2 twill running in one diagonal direction. Reverse the order and the diagonal runs the other way.

From there the variations come quickly. Tie up three shafts against one to produce a 3/1 twill (warp-faced and firm) or a 1/3 twill (weft-faced and soft). Reverse the treadling every eight or ten picks for a subtle herringbone. Change the threading to a point draw — 1, 2, 3, 4, 3, 2 — and you can weave diamonds or a chevron without altering the tie-up at all. Write the draft out on paper before you warp, and note which treadle sequence you use for each section of the sample.

Colour, Contrast and Weft Testing

Warp colour is where a sample rewards you most. Try stripes of two contrasting colours, perhaps four ends of each alternating across the width, and watch how the diagonal shifts where the colours meet. In a balanced twill, a dark warp and light weft will read very differently from the reverse, and a two-colour weft alternated pick by pick can produce a subtle, broken diagonal that looks far more complicated than it is.

Divide the warp into bands of 10 to 15 cm and change the weft at each boundary. Use the same yarn as the warp in one band, a finer yarn in the next, and a slightly thicker one after that. Keep your beat consistent, then deliberately weave one band with a softer beat to see what happens. Note your picks per inch as you go; this is the figure you will need when you scale up.

Warping a Short Sample Without Waste

Allow generously for loom waste. Forty centimetres at the back and a similar allowance at the front is realistic on most table and floor looms, and it is worth adding another 15 cm for tying on. A 120 cm warp will give you around 60 cm of usable cloth, which is ample once you cut it into sections.

Thread and sley carefully, check the threading twice, and tie on with even tension across the width. If you find you want to test more treadlings than the warp allows, cut off the finished sample, re-tie the remaining warp to the apron rod and carry on. Nothing is wasted.

Wet Finishing and Recording the Results

Cut the sample into labelled pieces and finish each one differently. Leave one as woven, hand-wash and press a second in cool water, and give a third a warm wash with gentle agitation to see how much it fulls. Measure every piece before and after, in both width and length, and work out the percentage shrinkage.

Then record everything on a card and keep it with the sample: yarn, sett, picks per inch, threading, treadling sequence, finishing method and shrinkage. Add a note on handle — did the cloth soften, did the diagonal stay crisp, would it suit a garment or a cushion? That card, not the cloth itself, is what makes your next warp straightforward. Sample once properly and the larger piece almost weaves itself.
